BSJ300L Aluminium Alloy 300 L/s Mechanical Booster Vacuum Pump 50Hz 5HP Army Green

Place of Origin China
Brand Name BSC
Certification CE
Model Number BSJ300L
Minimum Order Quantity 1 set
Price USD 3420 per set
Packaging Details Wooden Case
Delivery Time 5-30 days
Payment Terms T/T
Supply Ability 1000 sets per month
Product Details
Material Aluminium Alloy Motor Power 5hp
Voltage 380,440V Pumping Rate(50hz) 1000 M³/h (16667L/min)
Pumping Rate(60hz) 1200 M³/h (20000L/min) G.W. 128kgs
N.W. 115kgs Meas. 102*50*50cm
High Light

roots blower vacuum pump

,

mechanical booster vacuum pump

Leave a Message
Product Description

Whole Aluminium Alloy Made 300L/s 50Hz 5hp Army Green Booster Pump,Mechanical Roots Pump BSJ300L





Description :



We offer you a comprehensive consultationservice.

Only the vacuum technology combined with application experience can find the right solution.





Characteristics:



  • Special shaft seal is used to achieve the long stable running without oil leakage.
  • The use of oil-free intermediat seal,multiple sealed way to ensure the hight clean vacuum environment in the rotor chamber .
  • Advanced proceesing to ensure the good geometrical symmetry of the rotors,as well as low noise and long service life.
  • Compact structure,light weight and small volume .





​Technical Parameter :



Model Units BSJ300L
Pumping Rate 50 Hz m³h-1 / Lmin-1 1000/16667
60 Hz 1200/20000
Max allowed differential pressure 50 Hz Pa 7.3x103
60Hz Pa 6.0x103
Max Inlet Pressure 50Hz Pa 1.3x103
60Hz Pa 1.1x103



Ultimate Vacuum



mbar



4×10-4



Motor Voltage v 380V~440V
Motor Power kW(hp) 3.7 (5.0)
Inlet -- VG100
Outlet -- VF80
Flow Rate L/min 3
MPa 0.1
Water Temp. 5~30
Oil Need L 2.0
Ambient Temp. 5~40
Vacuum Pump Oil -- BSO-46



Note: The value of 'Ultimate Pressure' in this sheet is measured by Pirani gauge when the Baosi special pump oil is used,and the value should be 4x10-3 if the Mcleod gauge is used.





Performance Curve:



BSJ300L Aluminium Alloy 300 L/s Mechanical Booster Vacuum Pump 50Hz 5HP Army Green 0





Dimensions:



BSJ300L Aluminium Alloy 300 L/s Mechanical Booster Vacuum Pump 50Hz 5HP Army Green 1BSJ300L Aluminium Alloy 300 L/s Mechanical Booster Vacuum Pump 50Hz 5HP Army Green 2





BSJ300L Aluminium Alloy 300 L/s Mechanical Booster Vacuum Pump 50Hz 5HP Army Green 3



Applications

It can be matched with backing pump used in Leak testing systems,Vacuum Coating,Semiconductor production,Vacuum Furnace,Chemistry ,Electric Power Engineering,Machinofacture,

Optical Filming,Solar energy,Analysis and laboratory and other so many fields.
